Establishing an ecosystem for integrated 2D materials in the semiconductor industry
The 2D-Pilot Line (2D-PL) project aims to further strengthen the European ecosystem in the development of integration modules for photonics and electronics prototyping services. It will work to mature semiconductor technologies and provide information to aid industrial uptake. This four-year project builds on the foundation of the 2D-Experimental Pilot Line project (2D-EPL) which first began the work toward integrated 2D materials in the semiconductor industry. The 2D-PL will offer comprehensive prototyping services for the integration of graphene and TMDCs on established semiconductor platforms that use silicon technologies.
The 2D-PL offers multi-project wafer (MPW) runs in which customer designs are included as dies on joint wafers where you can "share the mask to share the costs”. Currently there are three MPW offerings available for CMOS devices, biosensors and photonics applications.
Whether you have questions about how to become involved in the project, our upcoming multi-purpose wafer runs or engaging in tailor designed projects with our partners, this entry point is the place to engage with the 2D-PL.
