Synthesising and characterising layered materials
The Enabling Materials Work Package has developed scalable synthetic routes for the synthesis and characterisation of layered materials. The team has optimised the properties of these materials to the point of matching the ones of pristine mechanical exfoliated materials.
The last 10 years
Ten years ago, high-quality graphene was usually isolated mainly through mechanical exfoliation of graphite, which was hard to scale up. This prompted us to develop scalable synthetic routes, including chemical vapour deposition (CVD), liquid phase exfoliation, ultra-high vacuum surface synthesis, electrochemical exfoliation, etc. We have mastered our scalable methods to produce high-quality, transferable graphene at a wafer scale, matching the properties exhibited by mechanically exfoliated materials.
The discovery of graphene was the beginning of a new era. Thousands of exfoliable, bidimensional materials with intriguing and useful properties have been developed and used to build functional heterostructures and devices for electronics, spintronics or optoelectronics. For example, we have mastered the synthesis of hexagonal boron nitride and transition metal dichalcogenides and stacked them to create heterostructures. We are also scaling up the production of homostructures which can be twisted at predetermined angles to obtain new phenomena that are absent in a single layer. We are also optimising the growth of graphene nanoribbons with tailored geometry and the synthesis of 2D polymers and metal–organic frameworks (MOFs). Finally, we have been able to exfoliate non-layered materials using liquid-phase exfoliation and epitaxial growth of ultrathin layers.
During the last three years, the Enabling Materials Work Package has contributed to more than 70 joint publications.
This year’s progress
In 2022, the Enabling Materials Work Package worked on the production of twisted bilayer graphene using CVD-grown single graphene layers which were then assembled into a twisted bilayer structure. This represents a proof-of-concept demonstration for future large-scale assemblies.
Furthermore, the researchers published their results on field-effect transistors made of single-layer molybdenum disulphide and a thin dielectric layer of barium titanate (BaTiO3). The mobilities of these devices are much higher than the ones of devices made with other dielectrics, such as silicon dioxide, and comparable to hexagonal boron nitride. Thanks to the demonstrated hysteresis of the current vs gate voltage, which disappears when the device is heated above a certain temperature, these tools could be applied to future memory storage devices.
Wang, Z. et al. Nat. Synth. 2022, DOI: 10.1038/s44160-021-00001-4
Piccinini, G. et al. Nano Lett. 2022, DOI: 10.1021/acs.nanolett.2c01114
Puebla, S. et al. Nano Lett. 2022, DOI: 10.1021/acs.nanolett.2c02395
